Safety Protection TRIAC Relays YS-3F Customizable Solder Resistant

Name: Safety Protection TRIAC Relays YS3F Customizable Solder Resistant
Brand: YSUN
Price: 1 USD

Brand Name : YSUN

Model Number : YS-3F

Certification : cULus:E509779/TUV:B1067040001/CQC:CQC21107292207

Place of Origin : China

MOQ : 100pcs

Price : negotiable

Payment Terms : T/T, Western Union, MoneyGram, L/C, D/A, D/P

Supply Ability : 500k per month

Delivery Time : 5-8 days

Packaging Details : standard or customization

Keyword : TRIAC Relays

Input voltage : 5/12/24VDC

Load voltage : 75-280VAC

Load current : 1A / 2A

Trigger mode : zero-cross / non zero-cross

Dielectric withstand voltage : 3000VAC

Mounting : PCB

Features : Dielectric strength 5000VAC

Contact Now

Safety Protection TRIAC Relays YS-3F Customizable Solder Resistant

TRIAC Relays Description:

The relay is an electrical control device, which can give a specified input quantity and keep it for a long enough time, so that the controlled quantity will undergo a predetermined step change in the electrical output circuit. When the input volume drops to a certain level and maintains for a long enough time, it returns to the initial state.

TRIAC Relays Features:

1. Load voltage can reach 280VAC

2. Zero-cross and non-zero-cross as trigger mode

3. Dielectric strength 5000VAC

TRIAC Relays Technical Parameters:

Electric parameters(Environment temperature:25℃)
Item		Symbol	Test condition	Min	Typical	Max	Unit
Input	LED Forward voltage	VF	IF=10mA		1.16	1.3	V
	LED Reverse current	IR	VR=6V IF=0mA		0.1	10	μA
Output	Peak off-state current	IDRM	VDRM=600V			100	μA
	Peak on-state voltage drop	VTM				2.5	V
	Holding current	IH	IFTM=Max			25	mA
	Rise rate off-state critical voltage	dv/dt	VDRM=600Vx1/√2		200		V/μs
Transmission	LED trigger current	IFT	VD=6V RL=100Ω		10		mA
	Turn-on time	Ton		1		10	ms
	Turn-off time	Toff				10	ms
	Insulation resistance	Riso	500VDC(input-output)		50		GΩ
Weight					0.58		g

TRIAC Relays Applications:

1. Traffic light system

2. Security systems

3. Computer peripheral interface

4. Remote system

Safety Protection TRIAC Relays YS-3F Customizable Solder Resistant

Product Tags:

Safety Protection TRIAC Relays

Solder Resistant TRIAC Relays

Safety Protection TRIAC Relays YS-3F Customizable Solder Resistant Images
