SOP8 Zero Cross TRIAC Relays 0.9A AC110V Output YS-C209ZS For Frezzer

Name: SOP8 Zero Cross TRIAC Relays 09A AC110V Output YSC209ZS For Frezzer
Brand: YSUN
Price: 1 USD

Brand Name : YSUN

Model Number : YS-C209ZS

Certification : cULus:E509779/TUV:B1067040001

Place of Origin : China

MOQ : 100PCS

Price : negotiable

Payment Terms : T/T, , Western Union, L/C, D/A, MoneyGram

Supply Ability : 500k per month

Delivery Time : 5-8 days

Packaging Details : standard or customization

Keyword : TRIAC Relays

Model : YS-C209ZS

Load voltage : 110VAC or 220VAC

Load current : 0.9A

Trigger mode : zero-cross

Pack : 50pcs/tube or 1K/reel

Package : SOP8

Features : Load current: 0.9A

Contact Now

SOP8 Zero Cross TRIAC Relays 0.9A AC110V Output YS-C209ZS For Freezer

TRIAC Relays Description:

YS-C209ZS SSR is a compact and small package with DIP8 or SOP8, weight only 0.6g.TRIAC output,zero-cross trigger,low noise,high endurance,dielectric withstand voltage 5000VAC,110 or 220VAC for load voltage,passed TUV and UL certifications,ideal for security

system,CNC,communication interface,PLC etc.

TRIAC Relays Features:

1. Dielectric withstand voltage:5000VAC

2. Load voltage: 110VAC or 220VAC

3. Load current: 0.9A

TRIAC Relays Applications:

1. Security system, such as access control

2. Industry field, like soldering machine

TRIAC Relays Technical Parameters:

Electric parameters(Environment temperature:25℃)
Item		Symbol	Test condition	Min	Typical	Max	Unit
Input	LED Forward voltage	VF	IF=10mA		1.16	1.3	V
	LED Reverse current	IR	VR=6V IF=0mA		0.1	10	μA
Output	Peak off-state current	IDRM	VDRM=600V			100	μA
	Peak on-state voltage drop	VTM				2.5	V
	Holding current	IH	IFTM=Max			25	mA
	Rise rate off-state critical voltage	dv/dt	VDRM=600Vx1/√2		200		V/μs
Transmission	LED trigger current	IFT	VD=6V RL=100Ω		10		mA
	Turn-on time	Ton		1		10	ms
	Turn-off time	Toff				10	ms
	Insulation resistance	Riso	500VDC(input-output)		50		GΩ
